GEPRC MARK5 - GEPRC ELRS Receiver Binding; ELRS Receiver Binding Mode; Taranis Transmitter Binding Command; ELRS Binding Success Indicator

9 / 19
Bind GEPRC ELRS Receiver
GEPRC's ELRS 868MHz, ELRS 915MHz, and ELRS 2.4G receivers have the same binding
methods
1. Power on and off the receiver three times in a row (with an interval of 1 second), the blue
light of the receiver flashes continuously twice, indicating that the receiver has entered
the binding state.
2. For Taranis X9D/X9D Plus/X9E and Taranis QX7, turn on the transmitter, go to the TOOLS
-ELRS, and select BIND to enter the binding state.
3. Until the blue light of the receiver changes from continuous double flashes to steady light,
it means the binding is successful. Turn off and then turn on the power of the receiver,
the blue light is always on, indicating that the link is normal.
1
2
对频成功
对频按钮
对频中
