Offline Operation
4-18 Plotter Parameters
Default Inkjet Parameters
Table 4-5 shows the plotter Inkjet parameters, their function, and the GGT
default setting for each. The parameters appear on the control panel screen in
the order they are listed in the table. Follow the instructions starting on page
4-12 to adjust the values for these parameters.
TABLE 4-5 PLOTTER INKJET PARAMETERS
parameter function default
Inkjet Velocity Sets maximum velocity along the X and Y-
axes to be used for printing with inkjet.
24 in/sec
Inkjet Acceleration Sets maximum acceleration along the X and
Y-axes to be used for inkjet printing.
2 Gs
Inkjet Strike Count Sets the number of passes on a character.
Higher value makes a darker annotation.
1 strike(s)
Offset Test DIM A Used for development or field service. 0 inches
Offset Test DIM B Used for development or field service. 0 inches
Offset Test DIM C Used for development or field service. 0 inches
Offset Test DIM D Used for development or field service. 0 inches
X Pivot Offset Used for development or field service. 0 inches
Y Pivot Offset Used for development or field service. 0 inches
X Jet 1 Offset Used for development or field service. 0 inches
Y Jet 1 Offset Used for development or field service. 0 inches
IJ C Axis Home State 1, 2, 3, or 4 + 1
Offset Parameter Values
Values for Offset Test and Pivot Offset parameters are unique to each machine
and must be set individually using the procedure on page 4-12. Do not leave
the offset values at zero. Offset values of zero result in annotation printed with
the inkjet extremely out of position.
