Offline Operation
Setting the Pen and Inkjet Timers 4-21
Setting the Pen and Inkjet TimersSetting the Pen and Inkjet Timers
The Tool Timer function allows you to see the time remaining in the life of the
pen, check the remaining inkjet capacity, and reset the pen life and cartridge
life values.
The pen timer tracks the amount of distance that the pen tip has been in
contact with the paper. This is important if your plotter runs unattended. If you
set the pen timer (at the parameter entry screen), the plotter automatically
stops when the distance expires.
TO SET THE PEN TIMER
1. From page one of the Offline menu, press the Menu key one time to
display page two.
2. From page two of the Offline menu, press F4-Tool Tmr to display the tool
timer menu.
3. Press F1-Pen Timer to see the current values.
4. Do one of the following:
• Press F1-New Pen to restart the timer after installing a new pen.
• Press F2-Timer On to enable the timer.
5. Press F4-Exit until you reach page one of the Offline menu.
6. From page one of the Offline menu, press F2-Initialize to load the new
timer value.
TOOL TIMERS
PEN TIMER
INKJET TIMER EXIT
DISTANCE REMAINING
xxxxx YARDS
NEW PEN
TIMER ON EXIT
