Gerber Technology AccuPlot AP-300 User Manual

Offline Operation
Downloading Firmware 4-25
8. At the prompt:
Input file name for transfer===>>
type the release filename (included in the release notes) and press Enter.
at the plotter control panel:
You should now see a screen similar to the one below, indicating the
plotter is receiving the transmission.
The number of records, n, continues to increase as data is sent to the
plotter. If transmission errors occur, an error screen displays. From there
you can press F2-Retry to attempt the download again, or press F4-Exit to
return to page three of the Offline menu. If no errors occur, the following
screen displays:
Press F2-Program to replace the old version of the firmware.
9. Upon successful reprogramming, the following screen displays on the
plotter control panel.
at the host system:
10. Press Enter to reboot the system and return to the Power Up menu. Be
sure the new version number displays.
RECEIVING
# OF RECORDS = n
# EXPECTED = n EXIT
EPROM PROGRAM OK
HIT ANY KEY TO CONTINUE
COMPLETE
# OF RECORDS = n
# EXPECTED = n
PROGRAM EXIT
