10 LRR 1-52, LRR 1-53, URB 55 - Installation & Operating Manual - 850645-01
Usage for the intended purpose
LRR 1-52 and LRR 1-53 conductivity controllers can be used in combination with LRG 1x-x conductivity
electrodes and LRGT 1x-x conductivity transmitters as conductivity controllers and limiters in pressurised
steam and hot-water plants and in condensate and feedwater tanks. The conductivity controller indicates
when MAX or MIN conductivity has been reached, opens or closes a continuous blowdown valve and can
actuate an intermittent blowdown valve.
Configuration, operation and visual display
The equipment is configured and operated and information is viewed via the URB 50 or URB 55 visual
display and operating unit. The URB 55 is designed for installation in a control cabinet door or switch
panel. It may only be used when correctly installed. If you are using a URB 50, please pay attention to the
information in Installation & Operating Manual “LRR1-52-LRR1-53-URB50”.
Overview of possible unit combinations
Conductivity controller Conductivity electrode/transmitter Visual display and operating unit
LRR 1-52
LRG 12-2
LRG 16-4
LRG 16-9
LRG 17-1
LRG 19-1
URB 55
LRR 1-53
LRGT 16-1 / 16-2 / 16-3 / 16-4
LRGT 17-1 / 17-2
Fig. 1
Key to Fig. 1:
LRR = conductivity controller
LRG = conductivity electrode
LRGT = conductivity transmitter
URB = visual display and operating unit
To ensure the proper use of equipment for all types of use, please also read the Installation &
Operating Manuals for the system components used.
■
You can find the latest Installation & Operating Manuals for the system components named
in Fig. 1 on our website:
http://www.gestra.com/documents/brochures.html
