18 LRR 1-52, LRR 1-53, URB 55 - Installation & Operating Manual - 850645-01
Technical data - URB 55
Supply voltage
■
24 V DC ( ) +/- 20 %
Power consumption
■
Max. 14.4 W
Current input
■
Max. 0.6 A (at 24 V)
Required external fuse
■
10 A
Data transmission interfaces
■
2 x Ethernet 10/100 Mbit switched (Modbus TCP/IP)
■
1 x USB host port (versions 2.0 and 1.1)
■
1 x slot for SD card
Indicators and controls
■
Capacitive 5” touchscreen with LED backlight
■
Resolution 800 x 480 pixels (WVGA)
■
Brightness 200 Cd/m
2
, dimmable
■
Size (field of view) 110 mm x 65 mm
IP rating
■
Front: IP 66
■
Back: IP 20
Admissible ambient conditions
■
Service temperature: 0 °C – 60 °C
■
Storage temperature: - 20 °C – 70 °C
■
Transport temperature: - 20 °C – 70 °C
■
Air humidity: 5 % – 85 % relative humidity, non-condensing
Housing
■
Material: Front (metal/glass) / rear (metal electronics housing)
■
Housing attachment with the supplied fastening elements
■
Intended for installation in a control cabinet or switch panel
Dimensions, see page 26
■
Front panel (W x H) 147 x 107 mm
■
Switch panel cutout (W x H) 136 mm x 96 mm
■
Depth 52 mm + 8 mm protruding
