14 LRR 1-52, LRR 1-53, URB 55 - Installation & Operating Manual - 850645-01
Function
The LRR 1-52, LRR 1-53 conductivity controller is a 3-position stepping controller. It evaluates the signals
from a conductivity electrode (e.g. LRG 16-60, LRG 16-61 or LRG 17-60) or conductivity transmitter.
The conductivity controller indicates when MAX or MIN conductivity has been reached, opens or closes a
continuous blowdown valve and can actuate an intermittent blowdown valve.
Function tests and failure diagnosis can be performed using the URB 55 visual display and operating unit.
Behaviour when MIN/MAX conductivity is reached
If the minimum or maximum conductivity is reached, the appropriate output contact is opened.
What happens if the MAX limit is exceeded
■
If used as a conductivity limiter, the LRR 1-52, LRR 1-53 conductivity controller does not interlock
automatically when the MAX limit is exceeded.
Possible combinations of functions and equipment
Combining the LRR 1-52, LRR 1-53 conductivity controller with the conductivity electrodes, conductivity
transmitters and URB 55 visual display and operating unit provides the following common functions:
Conductivity controller LRR 1-52 LRR 1-53
Conductivity measurement with an LRG 1.-.. conductivity electrode and separate Pt
100 resistance thermometer (TRG 5-..)
or
Conductivity measurement with an LRG 16-9 conductivity electrode with integrated
resistance thermometer.
l
Evaluating the temperature-compensated current signal of a connected
LRGT 1x-x conductivity transmitter.
l
3-position stepping controller with proportional plus integral control (PI controller)
and actuation of an electrically operated continuous blowdown valve.
l l
MAX alarm when the conductivity limit is exceeded.
l l
MIN alarm when conductivity drops below the minimum limit.
Alternatively, MIN relay for automated intermittent blowdown.
l l
The valve position can be displayed if a potentiometer is connected (in the continuous
blowdown valve). The valve position is then shown on the URB 55 visual display and
operating unit.
l l
Switchable (DIP3) actual value/manipulated variable output, e.g. for remote actual value
display or direct connection to a continuous blowdown valve (manipulated variable
output)
l l
Volt-free input 24 V DC (standby) for inputting an external command
Control OFF / Valve CLOSED / Intermittent blowdown OFF
l l
Fig. 3
