DESCRIPTION OF CONNTECTING POINTS
J1 INPUT POWER
J2 OUTPUT POWER DC 24V
J3.J4 INPUT POINT
J5 CONNECTING J2 ( TO CIRCUIT BOARD)
J6.J7 OUTPUT POINT
J8 CONNECTING J1 ( TO CIRCUIT BOARD)
J9 CONNECTING J3 (TO CIRCUIT BOARD)
YO PIN PUNCH
Y1 PRESTRETCH MOTOR START
Y2 PRESTRETCH MOTOR LOW SPEED
Y3 PRESTRETCH MOTOR ACCOMDIATE
Y4 TURNTABLE START
Y5 TURNTABLE LOW SPEED
Y6 CARRIAGE RISING
Y7 CARRIAGE LOWERING
Y8 STARTING LIGHT
Y10 CARRIAGE LOWERING SPEED (Program C)
Y12 TURNTABLE BREAK
XO CARRIAGE UP LIMIT 0
X1 CARRIAGE DOWN LIMIT 1
X2 CARRIAGE HEIGHT PHOTO SENSOR 2
X3 PRE-STRETCH LIMIT 3
X4 TURNTABLE ALIGNMENT PROXIMITY 4
X5 START BUTTON 5
X6 RESET BUTTON
X7 PAUSE BUTTON
X8 POWER CUT CIRCUIT
VR3 PHOTO EYE SENSOR DELAY TIMER
1. INCREASE OVER WRAP HEIGHT
2. PHOTO SENSOR DELAY WHEN THE SPACE
BETWEEN THE PACKING OBJECT IS LARGER
