Get Packed EXP-108W - Page 57

PART LIST FOR EXP-108W
KEY NO PART NO DESCRIPTION Q'TY
27 PJ300200 CARRIAGE UNIT UPPER SEAT 1
28 32903004 MOTOR SV-A10 1
29 10250616 SCREW M6x16L 2
30 PJ308600 FIX PIECE 1
31 PJ301500 LIMIT FIXED SEAT 1
32 7350TZ02 LIMIT SWITCH TZ-7110 1
33 10130435 SCREW 2
34
PJ310100
PJ309200
PJ310110
GEAR →200% &250%
GEAR →230% &300%
GEAR →150% &250%
1
1
1
35 PJ303100 12 T CHAIN WHEEL 1
36 PG304000 PROXIMITY SWITCH SEAT 1
37 7355N105 PROXIMITY SENSOR PM12-04N 1
38 PB206100 BLOCK 10
39 PB206300 RING 2
40 PB206400 SPRING 2
41 PB206200 PLATE 2
42 PB202500 RING 2
43 3034HK02 BEARING HK 1010 2
44 PB202700 SWINGING BAR SHAFT 2
45 PJ309100 MOVING SHAFT SEAT 2
46 PJ302100 ROLLER SET 1
47 PJ308400 SUPPORTING SHAFT 1
48 10250616 SCREW M6*16L 1
49 PJ201000 RING 1
50 PJ303900 RING (UPPER) 1
51 PJ305100 RING 1
52 PJ303700 FILM SEAT SHAFT 1
53 PM302900 ADJUSTING RING 1
54 PM300600 RING (LOWER) 1
55 PM302400 SPRING 1
56 PM30050A-01 FILM FIX SEAT 1
