PART LIST FOR EXP-108W
KEY NO PART NO DESCRIPTION Q'TY
57 PM30050A-03 BRAKE DISC 1
58 PJ304100 FRICTION SEAT 1
59 30361730-01 BEARING NTB1730 1
60 PJ351500 ROLLER SET 1
61 PJ300500 LIMIT SEAT 1
62 7350TZ04 LIMIT SWITCH TZ-8108 2
63 PJ300800 SIDE PLATE 1
64 PJ309300 ACRYLIC DOOR 1
65 PJ306400 TERMINAL COVER 1
66 PJ301200 ISOLATED RING 2
67 11314200 C-RING R-42 4
68 30302030 BEARING 4
69 PJ300700 BEARING SEAT 4
70 PJ308000 PROTECTION RING 2
71 PJ301310 PRE STRETCH SHAFT 1
72 11301700 C-RING S-17 2
73 PJ309000 ISOLATED RING 1
74 PJ301410 PRE STRETCH ROLLER 1
75 PJ30010A ELEVATOR UNIT SEAT 1
76 PJ307800 SENSOR IDLE 1
77 PJ30270A PEDAL SHAFT 1
78 PJ30040A PEDAL 1
79 10140820 SCREW M8x20L 1
80 PJ304900 HING 2
81 10250616 SCREW M6x16L 1
82 PJ306500 SAFE PLATE 1
83 30392020 LINEAR BUSHING 1
84 PJ308600 FIX PIECE 2
85 7350TZ02 LIMIT SWITCH 2
86 PB202900 BLOCK 2
87 PJ302000 ROLLER SET 1
88 10190410 SCREW M4x10L 4
89 PJ310600 COVER 1
90 PG303700 SOLENOID 24 VDC TAU-1585 1
