Getac UX10 Series User Manual

9
Ref Component Description

Light sensor
Detects the surrounding lighting condition for
automatic adjustment of the LCD brightness.

P1 button
Opens or closes the OSD Control Panel.
When pressed longer:
Serves as the Ctrl+Alt+Del keyboard keys.

P2 button
The default function is Camera or Barcode Trigger
depending on your model.
Camera
Starts the G-Camera application.
Barcode
Trigger
Serves as the trigger button for the barcode
scanner if your model has the module.

Windows logo
button
Opens or closes the Start menu.

Plus button
Increases the sound volume.
Minus button
Decreases the sound volume.
Power button
Turns the power on or off. (The default “off” state is
“Sleep mode.”)
Speaker
Sends out sound and voice from your Tablet PC.
Microphone
Receives sound and voice to record voice.
Indicators
Power
Lights blue when the power is on.
Blinks blue when the system is in Sleep mode.
Battery
Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
CAUTION: Do not remove the battery during this period.
Blinks red (once per second) when the battery’s
capacity is below 10%.

Getac UX10 Series Specifications

General

Resolution	1920 x 1200 pixels
Storage	Up to 512GB SSD
Operating System	Windows 10 Pro
Rugged Features	MIL-STD-810H
Graphics	Intel Iris Xe Graphics
Wireless	Wi-Fi 6
Camera	Rear: 8MP
Security	TPM 2.0
Touchscreen	Capacitive
Connectivity	Optional 4G LTE
Display Size	10.1 inches
Processor	Intel Core i5 or i7
I/O Ports	USB 3.2 Gen 1 Type A x1 USB 3.2 Gen 2 Type C x1 Headphone / Microphone combo x1 DC in x1 Optional: Serial port (RS-232) x1, LAN (RJ45) x1, HDMI x1, Display Port x1, External antenna port for WWAN and GPS
