• The cables for 24 V must be placed in a cable duct/tray with the munber number K2xx as
shown in the illustration on the previous page. All cables for 24 V must be connected to the
electrical cabinet via cable duct K202 at the entrance to the cabinet on the right side. If the
object to which the cable is to be drawn is on the left side of the cabinet, the cables must be
drawn over the machine via cable tray marked K205 above the chamber. Place excess cable in
the cable tray on the top of the machine marked K205.
