ECturn Inside
10
Dimensions
5.1.5 Security sensors
X
Make sure that fixing screws and drill holes do not cross the motor gear unit.




 


*) Dimensions or positions can deviate depending on the door type
1 Security sensor "Open"
2 Security sensor "Close"
3 Drill hole Ø 8 mm for connection cable for the "Close" sensor
4 Drill hole Ø 8 mm for control unit connector cable.
5.2 Dimensions when installed in wooden frame
5.2.1 Main dimensions
















*) Dimensions or positions can deviate
depending on the door type
**) Values between by slightly bending
the lever
Dimensions
K
(mm)**
Spindle extension (mm)
11 without
17 6
24 13
27 16
31 20
