GEZE Perlan AUT-NT
4
Notes
à In accordance with Machinery Directive 2006/42/EC, a safety analysis must be performed and the door system
identied in accordance with CE Identication Directive 93/68/EEC before the door system is commissioned.
X
Enter the classication in accordance with DIN 18650-1 on the information plate and adhere the information
plate onto the drive housing so that it is visible from below.
X
Observe the latest versions of guidelines, standards and country-specic regulations, in particular:
à BGR 232 "Guidelines for power-operated windows, doors and gates"
à DIN 18650, Part 1 and Part 2 "Automatic door systems"
à DIN VDE 100-600 "Installation of low-voltage systems - Part 6 Tests"
à DIN EN 60335-1 "Safety of electrical devices for home use and similar purposes"
à Accident-prevention regulations, especially BGV A1 (VBG1) "General regulations", BGV A3 (VBG4) "Electrical
systems and equipment"
4.2 Mounting instructions
X
Observe the maximum permissible total current draw at the power pack for the drive unit for powering the
peripherals (max. 50 mA).
The sliding door drive is designed solely for use in dry rooms.
X
Use only cables specied in the cable plan.
X
Always use insulated wire-end ferrules for wire cores.
X
Insulate unused wires.
X
Secure loose, internal drive cables with cable ties.
4.3 Safety-conscious working
DANGER!
Danger of death from electric shock!
X
Before working on the electrical system, interrupt the power supply (mains) and check the safe isolation from
supply. Note that the system will still be supplied with power, despite the fact that the power supply is discon-
nected, if an uninterruptible power supply (UPS) is used.
X
Secure the workplace against unauthorised entry.
X
Take the swinging area of long system parts into account.
à Risk of injury when a sliding door drive is opened through moving parts (drawing in of hair, clothing …).
à Risk of injury by crushing, impact, shearing or drawing-in spots.
à Danger of injury by sharp edges in the sliding door drive.
à Risk of injury through breakage of glass.
4.4 Checking the mounted system
X
Check the measures for securing and avoiding trapping, knocking, shearing and hair etc. being drawn in.
X
Check the function of the contactors.
4.5 Disposing of the door system
The sliding door drive consists of materials that should be recycled.
The individual components have to be sorted in accordance with their material type:
à Metal (carrier plate, hanger bolt, …)
à Aluminium (track, cover, …)
à Plastic (roller carriage, …)
à Electronic components (controller, switch, …)
à Cables
The parts can be disposed of at the local recycling station or a scrap processing company.
