Mounting of the components
8.1 Requirement
à Cable laying to GEZE cable plan
à Mounting height for controller: from 850mm to maximum 1200mm above the top edge of the completed
ooring
8.2 Mounting the ush-mounted controller and power pack
The instructions describe the mounting recommended by GEZE of a connection variant with ush-mounted
controller and power pack.
X
Lay the 24-V output cable of the power pack
into the ush-mounted box (1).
1
X
Connect the 24-V output cable of the power
pack to the controller (2) in accordance with the
wiring diagram.
2
