TS 971 Industrial Door Control
7
Safety Brake – Drive Connection
21
22
23
24
25
26
2
12
11
S10
1
MOTOR
THERMAL
EMERGENCY
OPERATOR
SAFETY BRAKE
INTERLOCK
GN/W (N/C)
SAFETY BRAKE
REMOVE LINK TO
CONNECT SAFETY BRAKE
10 9 8
7 6 5
DIGITAL LIMIT
