GFA TS 971 - TS 971 - Connection of the Drive Unit to the Control Panel

TS 971 Industrial Door Control
4
TS 971 - Connection of the drive unit to the Control Panel
The Motor / Limit protected cable is available in 3m, 5m, 7m, 9m, 13m and custom lengths up to
25m. The Motor / Limit cable must not exceed 25m.
Fig 2
F1=,6A t
1.1
1.2
1.31.4
PIN Wire-No.
Description
1 3
Phase W
2 2
Phase V
3 1 Phase U
4 4 Neutral
5
PE Earth
PIN Wire-No.
Description
1 5
Safety Chain 24V DC
2
6 RS485 B
3 7 GND
4 8 RS485 A
5 9
Safety Chain
6 10 8V DC
DIGITAL
LIMIT ASSEMBLY
26 25
24
23 22
21
PE
N
W
V
U
[4]
[3]
[E]
[2]
[1]
PE
N
W
V
U
MOTOR PLUG
