Gigabyte G291-2G0 - BMC Network Configuration

BIOS Setup - 120 -
5-4-3 BMC Network Conguration
Select NCSI and Dedicated LAN
Switch NCSI and dedicated LAN and send KCS command.
Options available: Do Nothing/Mode1 (Dedicated)/Mode2(NSCI)/Mode3 (Failover).
Default setting is Mode1 (Dedicated).
Lan Channel 1
Conguration Address source
Select to congure LAN channel parameters statically or dynamically (DHCP). Do nothing option will not
modify any BMC network parameters during BIOS phase.
Options available: Unspecied/Static/DynamicBmcDhcp. Default setting is DynamicBmcDhcp.
Station IP address
Displays IP Address information.
Subnet mask
Displays Subnet Mask information.
Please note that the IP address must be in three digitals, for example, 192.168.000.001.
Router IP address
Displays the Router IP Address information.
Station MAC address
Displays the MAC Address information.
Real-time synchronize BMC network parameter values
Press [Enter] to synchronize the BMC network parameter values.
