BIOS Setup
English
Integrated Peripherals
Figure 4: Integrated Peripherals
On-Chip Primary PCI IDE [Enabled]
On-Chip Secondary PCI IDE [Enabled]
IDE1 Conductor Cable [Auto]
IDE2 Conductor Cable [Auto]
USB 1.1 Controller [Enabled]
USB 2.0 Controller [Enabled]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
AC97 Audio [Auto]
AC97 Modem [Auto]
Onboard H/W Serial ATA [Enabled]
Serial ATA Function [RAID]
Onboard ATA/RAID Device [Enabled]
RAID Controller Function [ATA]
Onboard H/W LAN [Enabled]
Onboard LAN Boot ROM [Disabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Serial Port 2 [2F8/IRQ3]
UART Mode Select [Normal]
x UR2 Duplex Mode Half
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x ECP Mode Use DMA 3
Game Port Address [201]
Midi Port Address [330]
Midi Port IRQ [10]
CIR Port Address [Disabled]
x CIR Port IRQ 11
Item Help
Menu Level X
If a hard disk
controller card is
used, set at Disabled
[Enabled]
Enabled onboard IDE
PORT
[Disabled]
Disabled onboard IDE
PORT
CMOS Setup Utility-Copyright (C) 1984-2002 Award Software
Integrated Peripherals
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F3: Language F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
To Next Page
