Gigabyte GA-X79-UP4 User Manual

- 11 -
Hardware Installation
USB

Chipset:
- Upto14USB2.0/1.1ports(8portsonthebackpanel,6portsavailable
throughtheinternalUSBheaders)

2 x Fresco FL1009 chips:
- Upto 4 USB 3.0/2.0 ports(2ports on the back panel,2ports available
throughtheinternalUSBheader)
Internal
Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

6 x SATA 6Gb/s connectors

4 x SATA 3Gb/s connectors

1 x CPU fan header

4 x system fan headers

1 x front panel header

1 x front panel audio header

1 x S/PDIF Out header

1 x USB 3.0/2.0 header

3 x USB 2.0/1.1 headers

1 x serial port header

1 x Clear CMOS jumper

1xTrustedPlatformModule(TPM)header
Back Panel
Connectors

1 x PS/2 keyboard/mouse port

1 x optical S/PDIF Out connector

1 x coaxial S/PDIF Out connector

8 x USB 2.0/1.1 ports

2 x USB 3.0/2.0 ports

2 x eSATA 6Gb/s connectors

1 x RJ-45 port

6xaudiojacks(Center/SubwooferSpeakerOut/RearSpeakerOut/Side
SpeakerOut/LineIn/LineOut/Microphone)
I/O Controller

iTE I/O Controller Chip
Hardware
Monitor

System voltage detection

CPU/System temperature detection

CPU/System fan speed detection

CPU overheating warning

CPU/System fan fail warning

CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.

Gigabyte GA-X79-UP4 Specifications

General

Memory voltage	1.5 V
Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	8
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Component for	PC
Motherboard chipset	Intel X79
Audio output channels	7.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA II, SATA III
On-board graphics card	No
Parallel processing technology support	4-Way CrossFireX, 4-Way SLI
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	2.0

Weight and Dimensions

Depth	305 mm
Width	244 mm
