Gigabyte GA-X79-UP4 User Manual

- 10 -
Hardware Installation
1-2 ProductSpecications
CPU Support for Intel
®
Core
™
i7 processors in the LGA2011 package
(GotoGIGABYTE'swebsiteforthelatestCPUsupportlist.)

L3 cache varies with CPU
Chipset

Intel
®
X79 Express Chipset
Memory

8 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory
* DuetoaWindows32-bitoperatingsystemlimitation,whenmorethan4GBof
physicalmemoryisinstalled,theactualmemorysizedisplayedwillbelessthanthe
sizeofthephysicalmemoryinstalled.

4 channel memory architecture

SupportforDDR32133/1866/1600/1333/1066MHzmemorymodules

Support for non-ECC memory modules

SupportforExtremeMemoryProle(XMP)memorymodules
(GotoGIGABYTE'swebsiteforthelatestsupportedmemoryspeedsand
memorymodules.)
Audio

Realtek ALC892 codec

HighDenitionAudio

2/4/5.1/7.1-channel

Support for S/PDIF Out
LAN

IntelGbELANchip(10/100/1000Mbit)
Expansion Slots

2xPCIExpressx16slots,runningatx16(PCIEX16_1,PCIEX16_2)
* Foroptimumperformance,ifonlyonePCIExpressgraphicscardistobeinstalled,
be sure to install it in the PCIEX16 slot.

2xPCIExpressx16slots,runningatx8(PCIEX8_1,PCIEX8_2)
* ThePCIEX8_2slotsharesbandwidthwiththePCIEX16_2slot.Whenthe
PCIEX8_2 slot is populated, the PCIEX16_2 slot will operate at up to x8 mode.
 (AllPCIExpressx16slotsconformtoPCIExpress3.0standard.)

2 x PCI Express x1 slots
 (AllPCIExpressx1slotsconformtoPCIExpress2.0standard.)

1 x PCI slot
Multi-Graphics
Technology

Support for 4-Way/3-Way/2-Way AMD CrossFireX
™
/NVIDIA SLI technology
Storage Interface

Chipset:
- 2xSATA6Gb/sconnectors(SATA30/1)supportingupto2SATA6Gb/sdevices
- 4xSATA3Gb/sconnectors(SATA22~5)supportingupto4SATA3Gb/sdevices
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* When aRAIDsetisbuiltacrosstheSATA6Gb/sandSATA3Gb/schannels,the
system performance of the RAID set may vary depending on the devices being
connected.

3 x Marvell 88SE9172 chips:
- 4xSATA6Gb/sconnectors(SATA36~9)supportingupto4SATA6Gb/sdevices
- 2 x eSATA 6Gb/s connectors on the back panel supporting up to 2 SATA 6Gb/s
devices
- Support for RAID 0 and RAID 1

Gigabyte GA-X79-UP4 Specifications

General

Memory voltage	1.5 V
Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	8
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Component for	PC
Motherboard chipset	Intel X79
Audio output channels	7.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA II, SATA III
On-board graphics card	No
Parallel processing technology support	4-Way CrossFireX, 4-Way SLI
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	2.0

Weight and Dimensions

Depth	305 mm
Width	244 mm
