Gigabyte GA-X79-UP4 User Manual

Appendix
- 90 -
Step 5:
After completing the settings above, click Start, point
to All Programs, point to Accessories, and then click
Sound Recorder to begin the sound recording.
Step 1:
Locate the
iconinthenoticationareaandright-click
on this icon. Select Recording Devices.
Step 2:
On the Recording tab, right-click on an empty space and
select Show Disabled Devices.
* Enabling Stereo Mix
If the HD Audio Manager does not display the recording device you wish to use, refer to the steps below. The
followingstepsexplainhowtoenableStereoMix(whichmaybeneededwhenyouwanttorecordsoundfrom
yourcomputer).
Step 3:
When the Stereo Mix item appears, right-click on this
item and select Enable. Then set it as the default device.

Gigabyte GA-X79-UP4 Specifications

General

Memory voltage	1.5 V
Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	8
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA III connectors	6
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Component for	PC
Motherboard chipset	Intel X79
Audio output channels	7.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA II, SATA III
On-board graphics card	No
Parallel processing technology support	4-Way CrossFireX, 4-Way SLI
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	2.0

Weight and Dimensions

Depth	305 mm
Width	244 mm
