Item Code Description
1 CN_NCSI NCSI Connector
2 SW_ID ID Button with LED
3 LAN1_2 1GbE LAN Port #1/#2 (MC13-LE0 Supported)
4 USB3_MLAN Server Management LAN Port (Top)/ USB 3.2 Gen1 Ports (Bottom)
5 LAN1 10GbE LAN Port #1 (MC13-LE1 Supported)
6 LAN2 10GbE LAN Port #2 (MC13-LE1 Supported)
7 COM_VGA Serial Port (Top)/ VGA Port (Bottom)
8 P12V_AUX 2x4 Pin 12V Power Connector
9 PMBUS PMBus Connector
10 CPU0_FAN CPU0 Fan Connector
11 ATX 2x12 Pin Main Power Connector
12 SYS_FAN5 System Fan Connector #5
13 SYS_FAN4 System Fan Connector #4
14 SYS_FAN3 System Fan Connector #3
15 SYS_FAN1 System Fan Connector #1
16 SYS_FAN2 System Fan Connector #2
17 SPI_TPM TPM Connector
18 SATA_0_1 SATAIII 6Gb/s Connector #0/#1
19 SATA_2_3 SATAIII 6Gb/s Connector #2/#3
20 USB_A USB 2.0 Type-A Connector
21 F_USB3 Front Panel USB 3.2 Gen1 Connector
22 FP_1 Front Panel Header
23 F_USB2 Front Panel USB 2.0 Header
24 IPMB IPMB Connector
25 M2_0 M.2 Slot (PCIe Gen5 x4, Supports NGFF-2280)
26 BP_1 HDD Backplane Board Connector
27 PCIE_1 PCIe x4 Slot (Gen4 x4)
28 LED_BMC BMC Firmware Readiness LED
29 PCIE_3 PCIe x16 Slot (Gen5 x16)
30 CASE_OPEN Case Open Intrusion Alert Header
31 BAT Battery Socket
