Operation with a router
COMFORT 550 / 550A / LUG_Kombi IM-Nord en / A31008-M3001-R201-1-SM19 / extending.fm / 4/11/22
58
Repeater with encryption
Registering a repeater
Connect the repeater to the mains power supply Press and hold the Registration/paging
key on the telephone base station (min. 3 secs) . . . the repeater is automatically registered
Up to 2 repeaters may be registered.
The ECO DECT function M
aximum Range is activated and the No Radiation function is
deactivated. The settings cannot be changed whilst the repeater is registered.
As soon as a repeater is registered, it wil
l appear in the repeater list under
De-registering a repeater
Operation with a PABX
To find out which settings are required for a PABX, please refer to the PABX user guide.
You cannot send or receive SMS messages on P
ABXs that do not support Calling Line
Identification.
Setting the flash time
Encryption is activated (default setting).
Settings Syste
m Repeater
Settings OK System OK Repeater OK use to
select repeater De-reg. Ye s
Operation with a router
When operating on the analogue connection of a router, any echoes that may occur can be
reduced by activating XES mode 1 (XES = eXtended Echo Suppression).
If the XES mode 1 does not sufficiently suppress the occurring echoes: activate XES mode 2.
press one of the following keys
OK Normal mode
OK XES mode 1
OK XES mode 2
If there are no problems with echoes, the normal mode (factory settings) should be
activated.
Settings OK Telephony OK Recall OK . . . possible flash
times are listed use to select flash time Select ( = selected)
