Operation with a PABX
Gigaset CL660A / LUG IE-UK en / A31008-M2804-L101-1-7619 / extending.fm / 3/2/18
Operation with a PABX
To find out which settings are required for a PABX, please refer to the PABX user guide.
Setting Tone or Pulse dialling mode
Setting the flash time
¤ . . . use to select Settings OK Telephony OK Recall OK
. . . possible flash times are listed . . . use to select flash time Select ( = selected)
Saving an access code (outside line code)
Setting the access code (e.g. "0") for dialling using the fixed line network.
¤ . . . use to select Settings OK Telephony OK Access
Code OK . . . then
Setting pauses
¤ . . . then
¤ . . . use to select Settings OK Telephony OK Dialling
Mode OK . . . use to select Tone or Pulse Select ( = selected)
Fixed line network:
¤ Access external line with: . . . use to enter or change access code,
max. 3 digits
Rule:
¤ For . . . use to select when the access code should be
dialled
Call Lists: The access code will only prefix numbers from a list (list of
answered calls, list of missed calls, answer machine list).
All calls: The access code prefixes all numbers dialled.
Off: The access code is deactivated and does not prefix any
telephone number.
Save:
¤ Save
Pause after line seizure: 1 sec
3 secs
7 secs
¤ OK
¤ OK
¤ OK
Pause after Recall key: 800 ms
1600 ms
3200 ms
¤ OK
¤ OK
¤ OK
Dialling pause (pause after access code): 1 sec
2 secs
3 secs
6 secs
¤ OK
¤ OK
¤ OK
¤ OK
