© TheGigRig Ltd 2013
31
3. TheGigRig True Bypass Matirx technology not only bypasses the pedals and patch leads, but also
bypasses any unused switches. In this example the pedals are completely bypassed, and the
guitar signal is goig through one switch in the G2 before being sent directly to the output
4. Now when a pedal is kicked in, the signal is sent directly to that pedal, then directly to the amp
bypassing all unused switches
5. When multple pedals are selected the output of the first pedal is connected directly to the input
of the next pedal selected in the chain.
