10.8 Configuration / Diagnostic Information
Each of these commands causes a response from the WindSonic.
Item
Command
Response
Type
and serial No.
D1
Y16120001
Software
version
D2
2368-110-01
Unit
configuration
D3
M2,U1,O1,L1,P1,B3,H1,NQ,F1,E2,T1,S4,C2,G0,K50,
Supply
Voltage
D5
+11.7v
Self-test
D6
See Section 12.2 Self-Test (Still Air)
ALIGNMENT LIMITS:0D59,0CF5
ALIGNMENT U:OD15 *PASS*
ALIGNMENT V:OD16 *PASS*
CHECKSUM ROM:AB7D AB7D *PASS*
CHECKSUM FAC:04F4 04F4 *PASS*
CHECKSUM ENG:082A 082A *PASS*
CHECKSUM CAL:A9C1 A9C1 *PASS*
Hardware
Configuration
D10
Serial Number : Y16120001
Software Version : 2368-110-01
Class : WINDSONIC (Gill Instruments Ltd)
Number of axes on this unit : 2
Axes tilted 45deg to horizontal plane
Analogue outputs: 2 (12bit)
Analogue output modes: 0-5V 4-20mA 0-20mA
Maximum output rate: 004Hz
Maximum base rate on this unit is 16Hz sampling
Available baud rates: 002400 004800 009600 019200 038400
Available messages: M1 M2 M3 M4 M5 M12 M14 M15
M16
Safe mode enabled
Parity control allowed: F1 F2 F3
Communication modes: RS232 RS485/422
