Gill WindSonic User Manual

WindSonic Doc No 1405 PS 0019 Issue 28 November 2019
55
Sx - Analogue Output Range
The following command is only valid for the WindSonic Option 3:
Item
Options
Command
Analogue Range,
Magnitude Scaling
(Set Analogue Output
Range)
0 – 5 metres per second
0 – 10 metres per second
0 – 20 metres per second
0 – 30 metres per second
0 – 40 metres per second
0 – 50 metres per second
0 – 60 metres per second
0 – 80 metres per second
(0-80m/s WindSonic 75 only)
Analogue output disabled
S1
S2
S3
S4
S5
S6
S7
S8
S9
Tx - Analogue Output Type (Voltage or Current)
The following command is only valid for the WindSonic Option 3:
Item
Options
Command
Voltage or Current output
(Set Analogue Output Type)
0 - 5 Volt
4 – 20 mA
0 – 20 mA
T1
T3
T5
Ux - Output Units
Item
Options
Command
Output
Units
Metres per second (M)
Knots (N)
Miles per hour (P)
Kilometres per hour (K)
Feet per minute (F)
U1
U2
U3
U4
U5
Yx – Analogue Output, Error Status Condition
Item
Options
Command
Output Level
Full Scale level toggling
Fixed Steady level
Pre-Set level toggling
Y1
Y2 nnn
Y3 nnn
Where nnn =000 to 200 see Para 9.7.10.
NOTE: This command is not applicable to WindSonic 75 analogue output units.
