24
Hydraulic Pump Repair Kit No. 1 (RPTS-KIT#1)
Repair kit No� 1 includes the following parts:
Description
10 Plunger O-ring
13 Intake Check Plug, 1/8in (in pump body)
14 Pressure Check Thrust Pin with O-ring
15 Pressure Check Plug, 1/8in (in pump body)
17 Port Plug, 1/8in (in pump body)
20 Pressure Relieft Thrust Pin with O-ring
Hydraulic Pump Repair Kit No. 2 (RPTS-KIT#2)
Repair kit No� 2 includes all parts in Pump Repair
Kit #1 and the following parts:
Description
8 Plunger Guide and Seal
11 Intake Check Ball
12 Intake Check Spring
16 Pressure Check Spring
18 Pressure Relief Plug, 3/8in
19 Pressure Relief Spring
21 Pressure Relief Pin
Included from Kit No. 1
10 Plunger O-ring
13 Intake Check Plug, 1/8in (in pump body)
14 Pressure Check Thrust Pin with O-ring
15 Pressure Check Plug, 1/8in (in pump body)
17 Port Plug, 1/8in (in pump body)
20 Pressure Relieft Thrust Pin with O-ring
Additional Items Available
Description
1
Part Number
Hydraulic Oil, 1/2 Pint Can RPTS-OIL
Pump Mounting Screw with
Nut and Washer
RPST-1KEY45-2
1
Additional items are not shown
