25
Corner Spring Assembly
NOTE: Corner Spring Assembly (4 required per Testing Screen) is interchangable on TS-1, TS-2, and TS-3�
1 2 3 4 52
Description Part Number
— Corner Spring Assembly (Complete) RPTS-CSA
1
CORNER SPRING PARTS
1 Corner Spring Stop Nut, 0�5in RPTS-CSA3
2 Corner Spring Cup Washer RPTS-CSA5
3 Corner Spring RPTS-CSA1
4 Corner Sping Flat Washer RPTS-CSA4
5 Corner Spring Bolt, 1/2x6�5in RPTS-CSA2
1
Assembly (Complete) includes all listed Corner
Spring parts
