44
B - Wristband Installation and Disassembly
Introduction
Velcro (1) Buckle Wristband Velcro (2)
Fig. A
One side of oximeter The other side of oximeter
Fig. B Wrist oximeter
Installation Procedure
Step 1: Insert the wristband to the oximeter from one side to the other side, as
shown in Fig. C.
Fig. C
Step 2: Put the oximeter on the wrist, and
stick the Velcro (1) to the inner side of wrist-
band, press the wristband to make the Vel-
cro (1) stick to the inner side of wristband
rmly, as shown in Fig. D.
Fig. D
ENGLISH
