Ginlong solis S6 Series User Manual

User Manual
4. Installation
17
5. Insert Seal and Clamp Finger into socket ,then tighten the nut , torque 4+/-0.5N·m.
4. Push Housing into Body.
6. The same installation for both cable end plug and socket connectors.
7. Mating plug andsocket: Push the plug into the socket completely, then rotate the
locker according to the direction instructed by the marks on thelocker.
Figure 4.17
Figure 4.18
Figure 4.19
Click
NOTE:
Before mating the plug and socket, please double check both AC Grid and
AC Backup connectors. Do not connect the grid cables to the AC Backup
port or connect the backup load cables to the AC Grid Port.
Otherwise, it may leads to malfunction or damage.
