C. MOUNTING THE AWNING
1. Lift the awning into position for fastening to the mounting brackets.
a. Ladders are usually sufficient however a scaffold or forklift may be used.
b. If using a forklift use all necessary caution to protect the surface of the
awning. Lift from the center of the awning to maintain product balance
while elevating.
2. Place the awning onto the brackets. Make sure the grooves of the awning are
securely engaged into the channels on the bracket. (Figure 3)
3. Secure the awning by moving the slide locks along the bottom awning track until
they are located under their respective brackets.
4. Once the final location of the slide locks has been achieved, tighten all set screws
on each slide lock with a 13mm or ½” wrench.
(FIGURE 3)
