D. MOTION SENSOR
NOTE: The Motion Sensor requires a hard wired 12V. D.C. connection.
12v DC MOTION SENSOR (Hard wired)
The Motion Sensor will come from the factory pre-programmed.
A hole may need to be drilled for the power cable.
1.
Locate the cable at the back of the awning cassette.
2.
Locate the nearest source of 12V. D.C. power.
3.
If required drill an appropriate sized hole, then feed the cable into the interior
of the vehicle and connect to a 12V. D.C. source or connect into an exterior
junction box with a 12V DC source.
4.
If necessary refer to the Motion sensor manual for instructions to program
the motion sensor.
Motion Sensor
