Technical specifications 25
Cod.nº 429043
Rev. No. 21/0519
Check table explanation in section 1.5.
In brackets: USA / CANADA specific values
Connection to power supply Iequ=16A Rsce=250 in accordance with UNE EN 61000-3-12:2012
Z min : (0.165+j0.109) Ohm EN 61000-3-11:2000
HS-6024 / EH060 1Ph
VOLTAGE
HEATING (*1)
TOTAL
POWER
TOTAL
CONSUMP.
SWITCH
CURRENT
CONDUCTOR
(*2)
kW
A
A
mm
2
(AWG)
200V
1ph + N
2ph
H / V 1.88 10.5 16
2.5 x 2 +
208V
1ph + N
2ph
H / V
1.88
10.1
16
2.5 x 2 +
(1.88) (10.1) (15) (12 x 2 + GND)
220V
1ph + N
2ph
H / V 1.88 9.5 16
2.5 x 2 +
230V
1ph + N
2ph
H / V 1.88 9.1 16
2.5 x 2 +
240V
1ph + N
2ph
H / V
1.88 8.8 16
2.5 x 2 +
(1.88) (8.8) (15) (12 x 2 + GND)
