GIRBAU HS-6032 - Page 26

Technical specifications 26
Cod.nº 429043
Rev. No. 21/0519
Check table explanation in section 1.5.
In brackets: USA / CANADA specific values
HS-6028 / EH070 3Ph
VOLTAGE
HEATING (*1)
TOTAL
POWER
TOTAL
CONSUMP.
SWITCH
CURRENT
CONDUCTOR
(*2)
Type
kW A A mm2 (AWG)
200V
3ph
H/V 3.0 8.7 10
2.5 x 3 +
E 14.7 42.4 50
16 x 3 +
208V
3ph
H/V 3.0 8.4
10
2.5 x 3 +
(10) (14 x 3 + GND)
E 15.8 43.8
63
25 x 3 +
(60) (4 x 3 + GND)
220V
3ph
H/V 3.0 7.9 10
2.5 x 3 +
E 17.5 46 63
25 x 3 +
230V
3ph
H/V 3.0 7.6 10
2.5 x 3 +
E 19.1 47.8 63
25 x 3 +
240V
3ph
H/V 3.0 7.2
10
2.5 x 3 +
(10) (14 x 3 + GND)
E 20.7 49.7
63
25 x 3 +
(60) (4 x 3 + GND)
380V
3ph
H/V 3.0 4.6 6
2.5 x 3 +
E 17.5 26.5 32
10 x 3 +
400V
3ph
H/V 3.0 4.3 6
2.5 x 3 +
E 19.2 27.7 32
10 x 3 +
415V
3ph
H/V 3.0 4.2 6
2.5 x 3 +
E 20.6 28.6 40
10 x 3 +
440V
3ph
H/V 3.0 3.9
6
2.5 x 3 +
(10) (14 x 3 + GND)
480V
3ph
H/V 3.0 3.6
6
2.5 x 3 +
(10) (14 x 3 + GND)
