OWNER’S MANUAL: MOTION 400
KEEP HANDS CLEAR OF HINGE PINCH POINT
Lay the base at before unfolding base.
ASSEMBLY
It is HIGHLY recommended to use two people for the installation of this product.
To assemble, please perform the following steps:
Carefully lift the base from the shipping carton, keeping the unit’s topside down.
Remove the plastic wrapping from the bottom to access the bases.
Insert hinge pins and secure with retaining clips.
Repeat on both sides of base.
Lay base at and unfold topside down.
Insert all 6 legs into the threaded holes and securely tighten
before turning base over for use. There must not be any gap
or wobble in the leg in order to avoid risk of injury or dam-
age to the base which may void warranty.
If installing on a platform base or foundation, do not install
legs. Follow the instructions included in the MULTIFUNC-
TION BRACKET accessory kit.
E
A
1
2
3
4
H
G
