2. INTENDED USE
The Quick Pull is intended for AUTO-REPAIR activities. It is not designed,
nor is it suitable, for lifting people. The hydraulic power lift must be used
inside the workplace and be protected from the weather (rain, humidity,
wind, etc.). The temperature of the workplace in which the lift will be
installed must never be less than 10 ° C nor above 40 ° C. The weight of the
structure and the maximum capacity limit are provided in this manual.
The Quick Pull has not been designed in such a way so that people may
perform operations of any kind beneath the lift’s structure or beneath its
support devices. Failure to take account the intended machine uses
described herein could lead to serious operator risks. The responsibility for
any such risks shall be borne by the operators themselves. The user is
required to use the lift in accordance with its intended use, with all of the
manufacturer's specifications, as well as in compliance with the current
workplace safety and accident prevention standards.
Important: The manufacturer shall bear no responsibility for any
damages caused to persons or property resulting from improper use,
carelessness or uses other than those for which the hydraulic power
lift is expressly intended.
2.1. Technical characteristics table
MEASUREMENT UNIT OF MEASURE
QUICK
PULL
Maximum capacity Kg-lb 2500 - 5513
Minimum platform height from the ground mm-inch 100-3.94
Maximum platform height from the ground mm-inch 1340 - 52.76
Platform length mm-inch 2622 - 103
Platform width mm-inch 783 – 30,8
Hydraulic power lift base length mm-inch 1705- 67.13
Hydraulic power lift base width mm-inch 730 – 28,73
Hydraulic circuit operating pressure bar-lb/inch
2
300 - 4213
Compressed air supply circuit pressure bar-lb/inch
2
8-110
Ascent time sec 40
Descent time sec 80
Electric motor power Kw/hp 2.2/1.6
Electrical power supply voltage Volt 230/380/400
Electrical power supply frequency Hertz 50/60
Auxiliary command circuit voltage Volt 24
Hydraulic power lift mass (weight) without accessories Kg/lb 865/548,4
Acoustic pressure level at the operator’s station: LpA Db(A) 54.5
Average acoustic pressure level considered: LpAm Db(A) 56.7
Acoustic power level: LwA Db(A) 73.6
Control unit oil quantity Litres/Gall 5/1.15
