2.3. “QUICK PULL” Hydraulic Power orientation
The frontal portion of the hydraulic power lift (as indicated in the diagram) is
the “side with the “hydraulic lifting jacks” and the control unit connections
outputs.
In order to obtain maximum stability upon the platform, always orient the
heaviest portion of the load at the front of the hydraulic power lift..
HYDRAULIC JACKS
FRONT SIDE
