Globalsat EB-3531 - Page 15

EB-3531
Specifications are subject to be changed without notice.
Page 15 of 21
Version 1.2.1
Table B-5 contains the values for the following example:
$GPGSA,A,3,07,02,26,27,09,04,15,,,,,,1.8,1.0,1.5*33
Table B-5 GSA Data Format
Name Example Units Description
Message ID $GPGSA GSA protocol header
Mode1 A See Table B-6
Mode2 3 See Table B-7
Satellite Used
1
07 Sv on Channel 1
Satellite Used
1
02 Sv on Channel 2
.
Satellite Used
1
Sv on Channel 12
PDOP 1.8 Position dilution of Precision
HDOP 1.0 Horizontal dilution of Precision
VDOP 1.5 Vertical dilution of Precision
Checksum *33
<CR><LF> End of message termination
1. Satellite used in solution.
Table B-6 Mode1
Value Description
M Manual-forced to operate in 2D or 3D mode
A 2D automatic-allowed to automatically switch 2D/3D
Table B-7 Mode 2
Value Description
1 Fix Not Available
2 2D
3 3D
GSV-GNSS Satellites in View
Table B-8 contains the values for the following example:
$GPGSV,2,1,07,07,79,048,42,02,51,062,43,26,36,256,42,27,27,138,42*71
$GPGSV,2,2,07,09,23,313,42,04,19,159,41,15,12,041,42*41
Table B-8 GSV Data Format
Name Example Units Description
Message ID $GPGSV GSV protocol header
Number of Messages
1
2 Range 1 to 3
Message Number
1
1 Range 1 to 3
