Globalsat TR-206 - Page 23

Timer 0
Timer
one time.
Enable/disable
TR-206 to send “OK”
E6 to server after GPRS
connection is
re-built.
Interval for switching
from validation to
RD
static state
if no motion detected
Traveled distance to
RE be judged as keep in
moving state
Interval for switching
from moving to static
RF
state
if no motion detected
Check GPS off time
RG setting (C7, C8, C9,
CA
GPS always on in
RH
moving state
Report Media for
RI changing from static
to moving
Report Media for
RJ changing from
moving to static
1/0
u16, in
seconds
u16,
Unit:
meter
u16, in
seconds
1/0
1/0
Media
type
Media
type
0=disable
1=enable
Available when E5 is not 0
0=Interval is the same with R1
0=Interval is the same with R1
0=disable
1=enable
0=disable
1=enable
W0 Start time
W1 End time
W2 Report interval
u32, in
seconds
u32, in
seconds
u16, in
seconds
0 ~ 86399
1 ~ 86400
0 ~ 65535
W3 Weekday mask u8, xx(hex
digits)
23
00 ~ 7f
Weekday is in hex-digit format
which specifies applicable day in
