2.10 Checksum
The checksum value is derived by the same method of NMEA standard. It is
calculated by ‘exclusive OR’ the 8 data bits of each character before “*” in the
sentence, but excluding “*”. The hexadecimal value of the most significant and
least significant 4 bits of the result are converted to two ASCII characters (0-9, A-F)
for transmission. The most significant character is transmitted first.
Example1: set the device whose IMEI is 011412000011274, the APN is internet, the user
name and password are not necessary, the server type is TCP, the server IP is
213.219.245.116, the server port number 20100.
The setup command is
GSS,011412000011274,3,1,D1=internet,D2=,D3=,D8=02,E0=213.219.245.116,E1=20100
*QQ!
Example2: Set TR-206 periodic report and ask it to report based on traveled distance
(P3) of 500 meters
The setup command is
GSC,011412000010789,M2(P3=500)*72!
The checksum is 72.
