Globalstar ST100 - Query Setup and Hardware Version

33ST100 User Manual v1 Confidential & Proprietary Information
8545-0194-01 v1.0
Where:
• RF channel : Valid values are: 0 = Channel A, 1 = Channel B, 2 = Channel C
• # of bursts: Valid values are: 0x01 thru 0x05 (1 to 5 bursts)
• Minimum Burst Interval: Units of 5 seconds. Valid values are: 0x01 thru 0x3C (5 to 300 seconds)
• Maximum Burst Interval: Units of 5 seconds. Valid values are: 0x02 thru 0x78 (10 to 600 seconds)
Example Command: AA 0E 06 00 00 00 00 00 03 18 30 00 CE 9C
Where the setup information is:
• RF channel : 00 Channel A
• # of bursts: 03 3 bursts per message
• Minimum Burst Interval: 18 0x18 = 24, 24 x 5 = 120 seconds
• Maximum Burst Interval: 30 0x30 = 48, 48 x 5 = 240 seconds
4.2.2.7. Query Setup (0x07)
The Query Setup command requests the ST100 BOARD to return the current setup parameters.
0x07
Command: AA 05 07 66 B0
Where:
• RF channel : Valid values are: 0 = Channel A, 1 = Channel B, 2 = Channel C
• # of bursts: Valid values are: 0x01 thru 0x05 (1 to 5 bursts)
• Minimum Burst Interval: Units of 5 seconds. Valid values are: 0x01 thru 0x3C (5 to 300 seconds)
• Maximum Burst Interval: Units of 5 seconds. Valid values are: 0x02 thru 0x78 (10 to 600 seconds)
Example Response: AA 0E 07 00 23 18 60 00 03 18 30 00 5D 60
LEADER LEN CMD CRC1 CRC2
AA 05 07 66 B0
HEADER LEN CMD RESERVED RF CHANNEL # OF BURSTS INTERVAL MIN INTERVAL MAX RESERVED CRC1 CRC2
AA 0E 07 XX XX XX XX
XX XX XX XX
XX 18 59
