GM INSTRUMENTS Osicus User Manual

Osicus User Guide V8 09/09/2021 Page 6 of 46
Option 1: Patient Environment for Non – Medically approved PC & Printer
If the PC and/or printer are not medically approved then NV2 should be positioned as
shown below, outwith the patient environment. The PC and/or printer must be compliant
to EN60950-1.
Figure 1: Patient Environment for Non-Medically approved PC & Printer
Option 2: Patient Environment for Medically approved PC & Printer
If the PC and/or printer is compliant to BS EN 60601-1 and medically approved, then the
Printer and PC can be positioned within the patient environment as shown below.
Figure 2: Patient Environment for Medically approved PC & Printer
In circumstances where the PC and /or printer are not medically approved but are to be
used within the patient environment then an isolation transformer, which is in
compliance to BS EN 60601-1 MUST be used to ensure safety compliance, or run the PC
on battery power without mains connection.
Osicus
Audiometer
Patient Environment (2 metres)
Headset and
Response Button
(2 metre)
USB cable
(2 metre max)
Osicus
Audiometer
USB cable
(2 metre max.)
Headset and
Response Button
(2 metre)
Patient Environment (4 metres)
