GMS B36 - USING THE MACHINE; Correct Connection of the Irons on the machine; Incorrect placement of the irons to be bent on the machine

B36
9
Figure 5: Incorrect connection of the irons on the machine
6.3. Incorrect placement of the irons to be bent on the machine
Incorrect connection of multi-irons
to be bent on the machine with
bending sleeves
Incorrect connection of multi-irons to be
bent on the machine with retainer
(5a)
(5b)
(6a)
(6b)
(6c)
