GMS B36 - 14 Machine Equipment List

B36
23
14. MACHINE EQUIPMENT LIST
PART NUMBER
DESCRIPTION
PIECE
B36-01
MACHINE BODY
1
B36-02
PLANET PLATE SHEET
1
B36-03
PLANET REDUCER STEM STEEL
1
B36-04
PLANET REDUCER
1
B36-05
ADJUSTMENT SPANNER
1
B36-06
PLATE
1
B36-07
CE LOGO - PLANET
1
B36-08
COVER HINGE
2
B36-09
ELECTRICAL PANEL
1
B36-10
M12 WASHER
4
B36-11
(M12X35 BOLT DIN933
4
B36-12
Ø70 BENDING SLEEVE
2
B36-13
Ø90 BENDING SLEEVE
1
B36-14
Ø110 LUK BENDING SLEEVE
1
B36-15
(Ø130 BENDING SLEEVE
1
B36-16
SWITCH PIN
6
B36-17
START BUTTON
1
B36-18
STOP BUTTON
1
B36-19
POWER LAMP
1
B36-20
GROUNDING TAG
1
B36-21
SENSOR
2
B36-22
ELECTRICAL PANEL CAP
1
B36-23
P1 BENDING BUTTON
1
B36-24
P2 BENDING BUTTON
1
B36-25
P3 BENDING BUTTON
1
B36-26
REAR CONNECTION PLATES
4
B36-27
LEFT CONNECTION PLATE
2
B36-28
M12 SPRING WASHER
16
B36-29
M12X60 BOLT DIN933
16
B36-30
BENDING PLATE ASSEMBLY
2
B36-31
ADJUSTMENT STUD
2
B36-32
FACE CONNECTION PLATE
2
B36-33
M10 SPRING WASHER DIN 1140
4
B36-34
M10x 30 BOLT DIN933
4
B36-35
ADJUSTER NUT
2
B36-36
M8X10 SETSKUR DIN914
1
B36-37
10X16X44 WEDGE
1
B36-38
BENDING FLANGE
1
B36-39
M6X10 BOLT DIN7985
4
B36-40
ZERO ADJUSTMENT PIN
1
