It ensures settings for protector bending
It ensures settings for hook bending
It changes machine's rotation direction to left or right.
It provides machine to be controlled automatically and manually.
Machine operates in normal mode. The bending is made
according to the preferred angle.
Programming Mode of the Machine
It provides machine system to engage.
It ensures switching the machine system off.
It indicates that there is electricity on the system when electricity
is supplied to the system when ON button is pressed.
It ensures rotation of bending flange.
11.1. Thermal flow setting range and motor protection switch
For a motor of 1.5 kW 1440 rpm it is set 5 A by machine manufacturer. It is not appropriate for
user to change settings. Motor protection switch is mounted to the machine in order to prevent damage
on the system by cutting the electricity current when excessive current is drawn by the system. If the
switch is tripped switch should be turned on by turning the button to position 1. Motor protection
switch should never be disassembled.
