GMS B36 - EQUIPMENT SUPPLIED WITH MACHINE

B36
8
6. USING THE MACHINE
6.1 Correct Connection of the Irons on the machine
Fixing the iron to be bent on the
machine with the help of retainer
(4a)
Fixing the iron to be bent on the
machine with the help of bending
sleeves.(4b)
Fixing the irons to be bent on the
machine with the help of retainer in
multi-iron bending (4c)
Fixing the irons to be bent on the
machine with the help of bending
sleeves in multi-iron bending (4d)
Figure 4: Placing the irons on the machine correctly
6.2. Incorrect placement of the irons to be bent on the machine
Incorrect placement of a single iron
to be bent with bending sleeves
(5a)
Incorrect placement of a single iron to
be bent with retainer (5b)
(4a)
(4b)
(4c)
(4d)
