3. SPECIFICATIONS
Electrical Specication Item
Model No.
GP-1750HD
Input
Characteristics
Voltage Range 10.5 - 16 VDC
Input Over Voltage Protection 16.5 VDC
Input Under Voltage Protection 10 ± 0.5 VDC
No Load Current
≤1 A
Output
Characteristics
Continuous Output Wattage 1750 W
Maximum Surge Rating 3500 W
Frequency 60 Hz ± 3 Hz
Output Voltage 120 VAC RMS +5/-15
Efciency ≥80%
Short-Circuit Protection System Shutdown
USB Output Voltage 4.75 - 5.25 VDC / 2.1 A
Output Waveform Modied Sine Wave
AC Output Connections 3 Standard North American Outlets
USB Connections 1 USB Ports
Signal and
Control
Remote Controller Panel Unit GP-REMOTE (optional)
Protection
Input Protection Over / Under Voltage
AC Output Protection Short-Circuit, Overload
Others Over / Under Temperature Protection
Environment
Operating Temp. 32° F - 104° F (-0° C - 40° C)
Storage Temp. 14° F - 122° F (-10° C - 50° C)
Storage Temp. & Humidity 10 - 95% RH
Dimension (L x W x H)
8.07” x 8.86” x 3.50”
(205 mm x 225 mm x 89 mm)
Weight 6.42 lbs (2.91 kg)
Cooling Thermostatically Controlled Fan
