INSTALLATION
CAUTION! Equipment Damage.
This Inverter cannot supply power to any AC distribution wiring or AC
loads in which the neutral and ground are connected (bonded). Doing
so will destroy the unit and void the warranty. If you do not understand
neutral to ground bonding, please have a professional install your system
for you. See section 4.8 GROUNDING for more information.
WARNING! Fire/explosion Hazard.
You may observe a spark when you make the nal battery connection
since current may ow to charge capacitors in the Inverter. Do not make
this connection in the presence of ammable fumes, as explosion or
re may result.
8.
Set the power switch to the ON position. Check the meters and indicators on the front
panel of the Inverter. The Function LEDs should be green showing the Inverter is ON.
If it does not, check your battery bank and the connections to the Inverter. The other
indicators should be OFF.
9. Set the Inverter switch to the OFF position. The indicator lights may blink and the internal
alarm may sound momentarily. This is normal. Plug the test load into the AC receptacle
on the front panel of the Inverter.
10.
Set the Inverter switch to the ON position and turn the test load on; the Inverter should
supply power to the load. If you plan to measure the output voltage of the inverter, a true
RMS meter must be used for accurate readings.
